802.11n 5.0MHz Wireless Double Head Ultrasound Probe

Certification
China Shenzhen Teveik Technology Co., Ltd. certification
China Shenzhen Teveik Technology Co., Ltd. certification
Customer Reviews
I am very glad to cooperate with you for so many years, I am very satisfied with your quality and delivery, and hope to cooperate in the future.

—— Richard Wisste

I'm very pleased with your adult finger clip, and our customers are very fond of it.

—— Adrian Letoven

In our years of cooperation, your service let me remember

—— Lakit Chrootemtek

Although your price is not very low, but your cost performance is very high, I hope you continue to work hard

—— Emil teppec

I'm Online Chat Now

802.11n 5.0MHz Wireless Double Head Ultrasound Probe

802.11n 5.0MHz Wireless Double Head Ultrasound Probe
802.11n 5.0MHz Wireless Double Head Ultrasound Probe 802.11n 5.0MHz Wireless Double Head Ultrasound Probe 802.11n 5.0MHz Wireless Double Head Ultrasound Probe 802.11n 5.0MHz Wireless Double Head Ultrasound Probe 802.11n 5.0MHz Wireless Double Head Ultrasound Probe

Large Image :  802.11n 5.0MHz Wireless Double Head Ultrasound Probe

Product Details:
Place of Origin: China
Brand Name: Teveik
Certification: CE
Model Number: WCU04CPL
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 3500
Packaging Details: 1pcs/box
Delivery Time: 7-10
Payment Terms: T/T
Supply Ability: 500sets/month

802.11n 5.0MHz Wireless Double Head Ultrasound Probe

Description
Scanning Mode: Convex& Phased+Linear Array Probe Frequency: Convex& Phased 3.5/5.0MHz Linear 7.5/10MHz
Probe Radius/Length: Convex 60mm; Linear 40mm Charging Mode: Wireless Charging
Image/video Storage: Storage On Mobile Phones, Tablet PC Power Source: Electricity
Type: Doppler Ultrasound Equipment Display Model: B,B/M,B+Color,B+PDI,B+PW
Elements: 192 Elements Battery Wotking Time: 2-3h According To Scan Mode
Working System: Android/ios/windows Download For Free
High Light:

5.0MHz Double Head Ultrasound Probe

,

Wireless Double Head Ultrasound Probe

,

802.11n Linear Array Ultrasound Probe

Wireless Double head Ultrasound probe Convex Phase and Linear Array Ultrasound Probe
Specification
Model
Convex & Phased+Linear array probe
Scan mode
B, B/M, B+COLOR, B+PDI, B+PW
Frequency
Convex&Phase 3.5/5MHZ Linear 7.5/10MHz
Display Depth
Convex&Phase 90-305mm Linear 20-100mm
Elements
192
Probe Radius/Length
Convex 60mm Linear 40mm
Wifi type
802.11n/2.4G
Image Adjust
B.GN(Bgain),D(depth) ; F(frequency); ENH(enhancement); TGC,DR(dynamicrange);Color/PW: GN,PRF, WF, Steer, Box
Measure
B:Length, Area, Circumference, GA,(CRL.BPD, GS, FL,HC, AC);B+M:hEART rate, Time, Distance, B-PW: Velocity, Hear Rate(2) S/D
Cinplay
Auto and manual, frames can set as 100/200/500/1000
Puncture assist function
in-plane puncture guide line, out-of-plane puncture guide line
Image/video Storage
Store on mobile phoes,Tablet PC
Power
Built-in lithium battery, replaceable
Battery working time
2-3h according to scan mode
Charging mode
wireless charging
Bootup
Platform dependent generally seconds
Working system
Android, IOS, Windows
Standard configuration
Host 1pcs
Dimensions
156(w)*60(d)*20(h)mm
Packing Size
185(w)*105(d)*55(h)mm
Net weight
250g
Gross Weight
750g
802.11n 5.0MHz Wireless Double Head Ultrasound Probe 0
802.11n 5.0MHz Wireless Double Head Ultrasound Probe 1
802.11n 5.0MHz Wireless Double Head Ultrasound Probe 2
802.11n 5.0MHz Wireless Double Head Ultrasound Probe 3
802.11n 5.0MHz Wireless Double Head Ultrasound Probe 4
802.11n 5.0MHz Wireless Double Head Ultrasound Probe 5
802.11n 5.0MHz Wireless Double Head Ultrasound Probe 6
Packing & Delivery
802.11n 5.0MHz Wireless Double Head Ultrasound Probe 7
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
