Product Details:
|
Scanning Mode: | Convex& Phased+Transvaginal Array Probe | Frequency: | Convex& Phased 3.5/5.0MHz Transvaginal 6.5/8MHz |
---|---|---|---|
Probe Radius/Length: | Convex 60mm; Transvaginal 13mm | Charging Mode: | Wireless Charging |
Image/video Storage: | Storage On Mobile Phones, Tablet PC | Power Source: | Electricity |
Type: | Doppler Ultrasound Equipment | Display Model: | B,B/M,B+Color,B+PDI,B+PW |
Elements: | 192 Elements | Battery Wotking Time: | 2-3h According To Scan Mode |
Working System: | Android/ios/windows Download For Free | ||
High Light: | Transvaginal Array Wireless Ultrasound Probe,Double Head Wireless Ultrasound Probe,3.5MHZ Transvaginal Array Ultrasound Probe |
Model
|
Convex & Phased+Transvaginal array probe
|
Scan mode
|
B, B/M, B+COLOR, B+PDI, B+PW
|
Frequency
|
Convex&Phase 3.5/5MHZ Transvagianl 6.5/8MHz
|
Display Depth
|
Convex&Phase 90-305mm Transvaginal 40-100mm
|
Elements
|
192
|
Probe Radius/Length
|
Convex 60mm Transvaginal 13mm
|
Wifi type
|
802.11n/2.4G
|
Image Adjust
|
B.GN(Bgain),D(depth) ; F(frequency); ENH(enhancement); TGC,DR(dynamicrange);Color/PW: GN,PRF, WF, Steer, Box
|
Measure
|
B:Length, Area, Circumference, GA,(CRL.BPD, GS, FL,HC, AC);B+M:HEART rate, Time, Distance, B+PW: Velocity, Hear Rate(2) S/D
|
Cinplay
|
Auto and manual, frames can set as 100/200/500/1000
|
Puncture assist function
|
in-plane puncture guide line, out-of-plane puncture guide line
|
Image/video Storage
|
Store on mobile phoes,Tablet PC
|
Power
|
Built-in lithium battery, replaceable
|
Battery working time
|
2-3h according to scan mode
|
Charging mode
|
wireless charging
|
Bootup
|
Platform dependent generally seconds
|
Working system
|
Android, IOS, Windows download for free
|
Standard configuration
|
Host 1pcs
|
Dimensions
|
270(w)*60(d)*20(h)mm
|
Packing Size
|
520(w)*100(d)*80(h)mm
|
Net weight
|
300g
|
Gross Weight
|
800g
|
